The PM111 is a high-performance pocket/keel mount, dual-band CHIRP transducer in a urethane housing. It has 16 internal broadband ceramic elements. The PM111 is available in either the Low & Medium bands, Low & High bands, or Low & High bands with a wide beam.
Specifications
| Feature | Specification |
|---|---|
| Low Frequency Band | 38-75 kHz |
| Medium Frequency Band | 80-130 kHz |
| High Frequency Band | 130-210 kHz |
| High Frequency Band - Wide Beam | 150-250 kHz |
| Housing | Urethane pocket/keel mount |
| Active Ceramic Elements | 16 |
| Beam Widths | 10-19° in Low band; 8-13° in Medium band; 4-8° in High band; 25° constant in High Band Wide-Beam |
| Temperature Sensor | Integrated sensor in transducer body |
| Transducer Cable | 10 meters (32.8 feet) with bare wire connection |
| Hull Material | Fiberglass only |
| Overall Height | 124mm (4.87") |
| Overall Width | 368mm (14.50") |
| Overall Depth | 136mm (5.34") |
| Recommended Boat Size | 9 meters (30 feet) and larger |
Available Models
| Version Name | Characteristics |
|---|---|
| PM111C-LM | Low (38-75 kHz) and Medium (80-130 kHz) bands |
| PM111C-LH | Low (38-75 kHz) and High (130-210 kHz) bands |
| PM111C-LHW | Low (38-75 kHz) and High (150-250 kHz) bands with wide beam |
