The P95 is an in-hull 300W CHIRP transducer that uses the same tank as the conventional P79. It is designed to transmit through solid fiberglass hulls. This unit operates in the Medium (95-155 kHz) band only.
Specifications
| Feature | Specification |
|---|---|
| Medium Frequency Band | 95-155 kHz |
| Housing | In-hull |
| Power Rating | 300W |
| Beam Widths | 17-26° in Medium band |
| Temperature Sensor | None |
| Transducer Cable | 10 meters (32.8 feet) with bare wire connection |
| Hull Material | Solid fiberglass |
| Overall Height | See diagram |
| Overall Width | See diagram |
Available Models
| Version Name | Characteristics |
|---|---|
| P95M | In-Hull single-band CHIRP transducer |
