The P155 is a puck-style, in-hull, widebeam 300W CHIRP transducer for bass and walleye boats. It is designed to transmit through fiberglass and aluminum hulls. This unit operates in the Medium (95-155 kHz) band only.
The in-hull design eliminates the risk of damage from external hazards such as sandbars or rocks.
Specifications
| Feature | Specification |
|---|---|
| Medium Frequency Band | 95-155 kHz |
| Housing | In-hull |
| Power Rating | 300W |
| Beam Widths | 17-26° in Medium band |
| Temperature Sensor | None |
| Transducer Cable | 10 meters (32.8 feet) with bare wire connection |
| Hull Material | Solid fiberglass or aluminum |
| Overall Height | 1.6" (4 cm) |
| Overall Width | 2.68" (6.8 cm) |
| Recommended Boat Size | Bass and walleye boats |
Available Models
| Version Name | Characteristics |
|---|---|
| P155C-M | In-Hull single-band CHIRP transducer |
