The M422 is a 1.5kW in-hull CHIRP transducer that chirps in the Low (47-52 kHz) and High (190-210 kHz) bands. It also functions as a conventional 50/200 kHz transducer.
The in-hull design eliminates the risk of damage from external hazards such as sandbars or rocks.
Specifications
| Feature | Specification |
|---|---|
| Low Frequency Band | 47-52 kHz |
| High Frequency Band | 190-210 kHz |
| Other Available Frequencies | 50/200 kHz |
| Housing | In-hull |
| Power Rating | 1500W |
| Beam Widths | 5° in High band; 18° in Low band |
| Temperature Sensor | None |
| Transducer Cable | 10 meters (32.8 feet) with bare wire connection |
| Hull Material | Solid fiberglass |
| Overall Height | 5.52" (14.0 cm) |
| Overall Width | 6.75" (17.1 cm) |
Available Models
| Version Name | Characteristics |
|---|---|
| M422C-LH | Dual-Band (Low/High) CHIRP transducer |
