The GT8HW-IH transducer is ideal for bass boats that want to install the transducer inside a fiberglass hull and not on the transom where cavitation could cause issues. It requires a flat section (under 6°) in the hull to be mounted and is excellent for boats traveling at high speeds that want to maintain accurate depth readings.The 8-pin transducer features high-wide CHIRP traditional sonar (145-230 kHz) and has a power rating of 250 W. It can be used in conjunction with a GT30-TM transducer and an adapter cable so you can maintain depth at high speeds and scanning capabilities at trolling speeds.
Specifications
| Feature | Specification |
|---|---|
| Part Number | 010-12401-10 |
| CHIRP Frequency Bands | High Wide 145-230 kHz |
| Power Rating | 250W RMS CHIRP |
| Housing | In-hull |
| Beam Width | 24-16° |
| Temperature Sensor | None |
| Transducer Cable | 20 ft with Garmin 8-Pin connector |
