The Garmin GSD 25 is a dual band network sounder for select GPSMAP models (see Garmin site for full list).
It is compatible with Airmar 1kW dual-band CHIRP transducers in the Low/Medium or Low/High bands.
Connection to the display is by a Garmin Marine Network cable.
Specifications
| Feature | Specification |
|---|---|
| Part Number | 010-01159-00 |
| Frequency Bands | 40-250 kHz |
| Transducer Connector | Garmin connector |
| Transducer Compatibility | For use with any Airmar 1kW dual-band CHIRP transducer, including wide-beam models. |
| Display Connection | Garmin Marine Network Cable |
| Compatible Displays | Select Garmin GPSMAP displays (see Garmin site for list) |
| Dimensions | 251mm (9.9") x 192mm (7.6") x 66mm (2.6") |
| Weight | 770g (1.7 lbs) |
| Power Supply | 10-35V DC |
