The Garmin GCV 10 is a dual band network sounder for use with echoMap and GPSMAP displays.
It is shipped with a Garmin DownVu/SideVu transom-mount transducer.
This sounder can only be used with the provided transducer. Connection to the display is by a Garmin Marine Network cable.
Specifications
| Feature | Specification |
|---|---|
| Part Number | 010-01156-02 |
| Frequency Bands | Low : 445-475 kHz; High : 805-840 kHz |
| Transducer Connector | Garmin connector |
| Transducer Compatibility | For use with included Garmin DownVu/SideVu transom-mount transducer only. |
| Display Connection | Garmin Marine Network Cable |
| Compatible Displays | Select Garmin echoMAP and GPSMAP displays (see Garmin site for list) |
| Dimensions | 251mm (9.9") x 192mm (7.6") x 66mm (2.6") |
| Weight | 845g (1.86 lbs) |
| Power Supply | 10-35V DC |
