The Raymarine CP200 is an entry-level single-band CHIRP network sounder. It is for use with Raymarine CHIRP/SideVision transducers only.
Connection to the display is by Raynet.
Specifications
| Feature | Specification |
|---|---|
| Part Number | E70257 |
| Frequency Bands | Not documented |
| Transducer Connector | Raymarine connector |
| Transducer Compatibility | For use only with Raymarine CHIRP/SideVision transducers (CPT-200). |
| Display Connection | Raynet |
| Compatible Displays | aSeries, cSeries, eSeries, eS Series, gS Series |
| Dimensions | 225mm (8.9") x 171mm (6.7") x 72mm (2.8") |
| Weight | 0.6 kg (1.32 lbs) |
| Power Supply | 12V DC or 24V DC |
| Other non-CHIRP Functionality | SideVision |
