The B175 and SS175 are large-bodied, through-hull, low-profile, single-band CHIRP transducers. They are available in either the Low, Medium or High band, or in the High band with wide beam, with a tilt of 0°, 12° or 20° to compensate for hull deadrise.
The Low band covers the popular 50 kHz frequency for deeper water, the Medium band covers the popular 88 kHz and 107 kHz frequencies for lake fishing, and the High band covers the popular 200 kHz frequency for salt-water fishing.
The B175 has a bronze housing and the SS175 has a stainless steel housing. They are otherwise identical.
The B175 and SS175 are the same size as the conventional B164 and SS164 transducers.
Specifications
| Feature | Specification |
|---|---|
| Low Frequency Band | 40-60 kHz |
| Medium Frequency Band | 85-135 kHz |
| High Frequency Band | 130-210 kHz |
| High Frequency Band - Wide Beam | 150-250 kHz |
| Power Rating | 1kW RMS |
| Housing | Through-hull, low-profile, bronze (B175) or stainless (SS175) housing with 0°, 12° or 20° tilt |
| Beam Widths | 21-32° in Low band; 11-16° in Medium band; 6-10° in High band; 25° constant in High band with wide beam |
| Temperature Sensor | Integrated sensor in transducer body |
| Transducer Cable | 10 meters (32.8 feet) with bare wire connection |
| Hole Size | Mounting hole diameter is 92.25mm (3.75") |
| Overall Height | 118mm (4.67") |
| Overall Width | 134mm (5.26") |
| Recommended Boat Size | Up to 11 meters (35 feet) |
Available Models
| Version Name | Characteristics |
|---|---|
| B175C-0-L | Low frequency band (40-60 kHz) with 0° tilt |
| B175C-0-M | Medium frequency band (85-135 kHz) with 0° tilt |
| B175C-0-H | High frequency band (130-210 kHz) with 0° tilt |
| B175C-0-HW | High frequency band (15-250 kHz) with 0° tilt and wide beam |
| B175C-12-L | Low frequency band (40-60 kHz) with 12° tilt |
| B175C-12-M | Medium frequency band (85-135 kHz) with 12° tilt |
| B175C-12-H | High frequency band (130-210 kHz) with 12° tilt |
| B175C-12-HW | High frequency band (150-250 kHz) with 12° tilt and wide beam |
| B175C-20-L | Low frequency band (40-60 kHz) with 20° tilt |
| B175C-20-M | Medium frequency band (85-135 kHz) with 20° tilt |
| B175C-20-H | High frequency band (130-210 kHz) with 20° tilt |
| B175C-20-HW | High frequency band (150-250 kHz) with 20° tilt and wide beam |
| SS175C-0-L | Low frequency band (40-60 kHz) with 0° tilt |
| SS175C-0-M | Medium frequency band (85-135 kHz) with 0° tilt |
| SS175C-0-H | High frequency band (130-210 kHz) with 0° tilt |
| SS175C-0-HW | High frequency band (15-250 kHz) with 0° tilt and wide beam |
| SS175C-12-L | Low frequency band (40-60 kHz) with 12° tilt |
| SS175C-12-M | Medium frequency band (85-135 kHz) with 12° tilt |
| SS175C-12-H | High frequency band (130-210 kHz) with 12° tilt |
| SS175C-12-HW | High frequency band (150-250 kHz) with 12° tilt and wide beam |
| SS175C-20-L | Low frequency band (40-60 kHz) with 20° tilt |
| SS175C-20-M | Medium frequency band (85-135 kHz) with 20° tilt |
| SS175C-20-H | High frequency band (130-210 kHz) with 20° tilt |
| SS175C-20-HW | High frequency band (150-250 kHz) with 20° tilt and wide beam |
